192 Point, digitally controlled, analogue audio patch bay routing system


Price excludes VAT

Product lists can be submitted to HHB for a packaged quotation

Add item to Quote List
Add item to Quote List


The Flock Audio PATCH XT System is a digitally controlled, 100% analogue audio patch bay routing system. A combination of Software known as the PATCH APP and a 192 Point Connection (96 Inputs & 96 Outputs) PATCH XT Hardware component allows users to easily route and control analogue audio routings without
having to resort to the use of manual patch cables.

The PATCH APP software application (OSX & Windows compatible) is designed with familiarity in mind. PATH’s in the application represent audio signal flows from top to bottom. Signal flows are divided up into single vertical columns allowing users to drag + drop available analogue audio equipment connected to the PATCH XT’s Hardware component. This analogue audio equipment is catalogued in the Hardware Index located to the left side of the PATCH APP.

The PATCH XT Hardware component is a 3U rack mountable unit that acts as the centrepiece hub of an audio equipment processing setup. Utilizing digital control over analogue audio signals is what makes the PATCH XT System unique and unlike anything else in the audio industry.

  • 192 Points – 96 Inputs x 96 Outputs
  • Phantom Power – 32 Channels
  • Front Panel I/O – 2 Inputs & 2 Outputs
  • Host Control – USB-B & CAT6 Network
  • LED Indicators – Power, Host, 48v
  • Multi-Unit Compatible – 8 Units
  • Rear Connectors – 25-pin DSUB


Cable Hanger XTH accessory available to support cables providing strain relief for the DSUB connections.
