DYNAUDIO Core 47

Core Series 47 3-way Loudspeaker

DYN-CR47L/DYN-CR47R

Price excludes VAT

Product lists can be submitted to HHB for a packaged quotation

Add item to Quote List
Add item to Quote List



Studio professionals need to trust the monitors they use every day. They need to know recordings will sound the same at 10pm as it did at 10am. And they need to know that they don’t need to worry about listener fatigue. Most of all, they need to be secure in the knowledge that they’re hearing everything that was recorded – warts and all – so they can make the best mixing decisions.

Trust is something that’s earned in this industry and Core 47 is ready to earn yours by giving you the most accurate reproduction that the latest technology and more than 40 years of expertise can provide. And when we say ‘accurate’, we really mean it: all Core monitors are calibrated to within a reference of 0.2dB at our factory in Denmark. You can install 100 and they’ll all perform to the same high standard.

Core 47 is the mid-size model of our flagship professional reference monitor series. Our engineers codenamed it ‘Bulldog’. You’ll know why when you fire it up.

This compact three-way monitor features an eyebrow-raising 500W + 500W + 150W of Class-D power from Pascal amplification, as well as sophisticated digital signal processing and a flat bass response down to 44Hz at -3dB, and 37Hz at -6dB with a gentle roll-off. And it reaches all the way up to 31kHz – never let it be said monitoring can’t give you a real high.

No more second-guessing

Let’s start at the top. Dynaudio studio monitors have always been famous for their revealing detail. The Esotar Pro tweeter takes the word ‘revealing’ to a new level. It’s the culmination of our engineers’ obsessive attention to driver detail, and uses innovative airflow technology (as well as a powerful neodymium magnet) to ensure that what went in, comes out.

Advanced manufacturing techniques and extensive measuring in our Jupiter testing facility have resulted in the ingenious Hexis inner dome. It sits just behind the tweeter diaphragm and optimises airflow to improving thermal response and eliminating unwanted internal resonances. The result is the best imaging, transient detail, and effortless high frequency response. It’s the kind of tweeter you can listen to long into the night during marathon mix sessions. Full detail and clarity, but no fatigue.

The 4in midrange driver provides staggering detail. It uses our proprietary MSP (Magnesium Silicate Polymer) material in its one-piece cone for the perfect balance of lightness, stiffness and damping. That, coupled with an aluminium voice-coil and neodymium magnet system, means an incredibly fast response and authoritative control. With crossover points at 475Hz and 5.25kHz, Core 47 delivers so much more of the critical vocal range in one driver than typical designs, ensuring your mix decisions on vocal balances and dialogue subtleties are made with confidence.

Core 47 and Core 7 share the same woofer. However, in a three-way design, this driver can focus on delivering deeper bass since midrange duties are handled by the 4in driver. This helps deliver the lower frequencies deliver awesome clarity, while the amplifier’s power and gentle roll-off let your ears (and your recordings) take full advantage of all the depth on offer. And, most importantly, all this deep energy is tonally accurate, letting you equalise bass instruments, kick drums, and all those subwoofer “booms” in the movies.

And because each driver is handmade in our factory in Denmark (we produce 1.4 million drivers each year for our home hi-fi, custom-install, in-car and pro-studio speakers), we can maintain incredibly small tolerances and deliver exceptional imaging. This consistency in each driver means you can use Core monitors in multiple studios and have them all sound and perform at the same high level – everything you need to hear, everywhere you go.

Placement options: we’ve left nothing to chance

We’ve made sure Core 47’s cabinet is stiff and inert, so all the vibration energy goes where it’s supposed to. That’s why we’ve given it a super-thick 44mm bezel, which contributes to its excellent linearity across the spectrum and means you can place it anywhere for a wide range of uses. We call them left and right, but you can use them tweeters-in or tweeters-out depending on your room and positioning. As with all Core speakers, we’ve put versatility high on our priority list.

Since every application is unique and monitors need to be placed in a variety of environments – either on their sides, vertically or sometimes even inverted with the woofer above the tweeter – we’ve designed Core 47 with indentations on all four sides. We’ve even developed special isolation pads that can be placed in order to protect the cabinet’s finish and halt vibrations from the mounting surface.

That goes for multi-channel set-ups, too: we’ve also designed special brackets have to mount Core 47 in orientations suitable for surround sound, immersive audio and other custom configurations.
