Broadcast Audio Object Authoring Tool


£13,650.00 Price excludes VAT

Product lists can be submitted to HHB for a packaged quotation

Add item to Quote List
Add item to Quote List


The Dolby DP590 Broadcast Audio Object Authoring tool is a key element of Dolby’s industry leading object-based audio authoring toolkit that assists broadcasters, live audio mixers, and engineers in the adoption and deployment of immersive audio for live events.

Dolby’s object-based audio (OBA) authoring toolkit for broadcast applications consists of the DP590 Broadcast Audio Object Authoring tool (DP590), the DP591 Audio Encoder (DP591), and the DP580 Professional Reference Decoder (DP580). This toolkit provides the ability to do immersive audio authoring, encoding, and monitoring.

The DP590 provides a user-friendly interface to give the audio engineer easy access to set up and deliver a new immersive audio experience as channel-based audio (e.g. 5.1.2, 5.1.4). It does this by ingesting audio groups from the mixing console and providing a simple way to create object audio presentations, including mapping sounds to locations in 3D space, and developing associated metadata. It also provides an easy way to monitor the changes to the immersive audio content that has been created, including emulating different speaker configurations.

The DP590 wraps around an audio mixing console as show in the diagram shown below. It enables audio engineers to define and monitor the various combinations of the audio elements that they wish to create. Each defined combination is referred to as a Presentation, and downstream decoders can be set to decode and render each presentation — for example, “5.1 English” — whenever this is required. The metadata used within the presentation is fully defined in the DP590 and is therefore under the control of the audio engineer. Presentations can be appropriately named for the production and may refer to languages, targeted delivery paths, or enhanced experiences as desired by the producers.

Simplified live production workflow

DP590 Workflow diagram

Technical benefits

      • Supports the creation of the different presentations and the associated metadata required for immersive audio delivery.
      • Provides local confidence monitoring of the presentations created for different playback environments without the need for additional equipment.
      • Supports loudness measurement of the monitored presentation to ensure regulatory compliance.
      • Provides proven design and reliability for installation in existing OB trucks.
      • Interfaces with industry leading mixing consoles and provides external control of DP590 functionalities from existing mixing consoles thru GPIO using JNIOR device.
      • Provides an easy to use user interface that simplifies the process of creating immersive audio for live events.

Business benefits

    • Eliminates the need for broadcasters to make a major investment in new production capabilities to deliver compelling immersive audio entertainment experiences to the home and on mobile.
    • Works with existing microphone configurations with limited modification needed to bring fans closer to the action. Allows broadcasters to deliver immersive audio for live events that leverages the growing number of Dolby Atmos enabled playback devices.
    • Supports the transition to 4K/UHD/HDR with enhanced audio experiences while allowing these experience to get better over time as platforms and skills develop.
    • Simplifies the workflow for live production of immersive audio.
    • Gives producers and audio mixers the creative freedom to mix audio as desired to create the immersive audio experience that will pull fans into the action.
